| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE, ISO, SGS |
| Model Number: | FF-12A |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden case |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 100 pcs per month |
| Material: | 304 Or 316 Stainless Steel | Control Box: | Electric Control Box |
|---|---|---|---|
| Key Selling Points: | High Accuracy, Easy Operate | Equipped With Gas Source: | 0.4-0.6mpa Clean And Stable Gas Source |
| After-sales Service: | Video Technical Support, Free Spare Parts, Field Installation, Commmissioning And Training, Field Maintenance And Repair Service, Online Support | Application: | Chemical, Food, Machinery & Hardware, MEDICAL |
| Packaging Type: | Bags, Bottles, CANS, Cartons, Pouch, Stand-up Pouch | Filling Material: | Granule |
| Filling Speed: | 800-1500 Bags/hour | Function: | Weighing And Filling |
Main Features:
1. Widely used for various granular products.
2. It can be weighing, auto filling and bags clothing.
3. Easy to be in stalled and convenient to be operated.
Function character:
1. Matching high precision sensor with high intelligent meter.
2. Self -adapted software, amending fall automatically, overrun alarming and inspecting trouble automatically
3. Automatic statistic function of the packing number and quantity
4. Print and data communication function.
5. Adopting import pneumatic actuator which is reliable, non-polluted and easy to be maintained.
6. The part touch the material use stainless steel which is safe, clean and not easy to be eroded and life of equipment is long.
Technical parameters:
| Model | FSA-25 |
| Filling capacity (KG) |
1-25 (Can be customized according to customer requirements) |
| Filling speed (BPM) | 1-10/min |
| Power supply (VAC) | 220/380V 50/60HZ |
| Power (KW) | 3.5 |
| Dimensions (MM) | 2200×1300×3000 |
| Net weight (KG) | 520 |
