Material: | 304 Or 316 Stainless Steel | Automatic Grade: | Automatic |
---|---|---|---|
Packaging Type: | Glass Jar Bottles | Bottle Type: | Glass Bottle Cans |
Packaging Material: | Metal, Glass | Function: | Auto Feeding Screwing Pressing Caps |
Capping Type: | Screw Capping Locking | Capping Speed: | 30-60 Bottles/Min |
Warranty: | 1 Year | Core Components: | PLC, Engine, Motor |
Voltage: | 380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ | After-sales Service: | Video Technical Support, Free Spare Parts, Field Installation, Commmissioning And Training, Field Maintenance And Repair Service, Online Support |
High Light: | 15BPM Screw Capping Machine,3PH Screw Capping Machine,1.5KW jar filling and capping machine |
Technical parameters:
Model | FAS-80 |
Bottle height | 50-200 MM |
Cap size | 30-80,80-120 MM |
Bottle diameter | 30-120 MM |
Capping speed (BPM) | 15-25 B/Min |
Power supply (VAC) | 220V 50/60HZ |
Power (KW) | 1.5 |
Dimensions (MM) | 1000x800x1600 |
Net weight (KG) | 240 |
Sample style:
