Detail Information

Material:	304 Or 316 Stainless Steel	Key Selling Points:	Fully Automatic, High-accuracy, Easy To Operate
Application:	Food, Beverage, Commodity, MEDICAL, Chemical, Machinery $ Hardware	Packaging Type:	Bottles
Bottle Type:	Plastic Bottle Glass Bottle Cans	Packaging Material:	Plastic, Metal, Glass
Function:	Auto Feeding Screwing Pressing Caps	Capping Type:	Screw Capping Locking
Capping Speed:	30-60 Bottles/Min	Warranty:	1 Year
Core Components:	PLC, Engine, Motor	Control:	PLC+ Touch Screen
Highlight:	30Bottles/Min Screw Capping Machine , 0.75KW Screw Capping Machine , 60HZ jar cap sealing machine

Product Description

Linear Plastic Jar Cap Sealing Machine Speed In 30-60 Bottle Screw Capping Machine

Product description:

Automatic capping machine is suitable for packaging volume of aluminum caps. This machine compared with other similar products is notable with the advantages: First, using a four-claw head balance-type for sealing the caps in uniform force; the second is having to make the shape of the bottle by bottle deformation, and then rolling thread flange sealing function. Also, the machine has a beautiful appearance, compact structure, reasonable design, stable operation, low noise, sealing speed, good sealing quality, and suitable for all kinds of wineries, beverage plants, breweries, pharmaceutical plants and other production companies. While the machine is multifunctional by changing different head parts to seal different kinds of caps like three anti-plastic cover cap and cover, chrysanthemum cover.

Working principle of machine: Drive the rotation of main shaft from the dynamic of motor by the gear reducer; The rotation among curve camshafts is converted into the force which drives the capping head to move upward and downward; At the same time the gear reduce drives the curve camshaft in the bottom to make the star wheel move intermittently which matches up with the up-and-down movement of capping head. The upper variable speed motor let the capping head works by driving the belt; When the star wheel rotates the bottles below the capping head which punches the binding face between cap inner liner and bottle mouth; Meanwhile the fit thread screw is completed from the the flanging and rolling pilfer proof ring. Finally the perfect capping effect comes out.

Note: Other sizes can be customized according to customer's products

Technical parameters:

Model	FAS-140
Bottle height	100-350MM
Cap size	15-60MM
Capping speed (BPM)	20-35 B／Min
Power supply (VAC)	220/380V 50/60HZ
Power (KW)	0.75
Dimensions (MM)	2300x900x1600
Net weight (KG)	320

Rotary fixed structure: (It is convenient to replace the turntable, easy to operate and faster.)

Tag:

Place of Origin:	China
Brand Name:	Fair Machinery
Certification:	CE, ISO, SGS
Model Number:	FAS-140

Minimum Order Quantity:	1
Packaging Details:	wooden packaged
Delivery Time:	10-20 days
Payment Terms:	T/T, Western Union. L/C
Supply Ability:	100 pcs per month
