| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE |
| Model Number: | FFC-1A |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden packaged |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 10 pcs per month |
| Material: | 304 Or 316 Stainless Steel | Packaging Material: | Plastic, Glass |
|---|---|---|---|
| Capping Way: | Pneumatic Lower Lid System | Core Components: | PLC, Touching Screen, Frequency Converter |
| Automatic Grade: | Fully Automatic | Key Selling Points: | Fully Automatic, High Accuracy, Easy To Operate, Low Cost |
| Equipped With Gas Source: | 0.4-0.6mpa Clean And Stable Gas Source | Application: | Beverage, Chemical, Commodity, Food |
| Function: | Filling, Sealing, Capping | Special Function: | With Hand Feeding Cap |
| High Light: | 6B/Min Jar Filling And Capping Machine,3.8KW Jar Filling And Capping Machine,PLC syrup sealing machine |
||
Automatic lower lid for jam plastic barrel Syrup jam filling and capping machine production line
The weighing filling and sealing production line is an automatic weighing filling and capping machine, equipped with an automatic capping system, which can automatically lower and automatically cap. The equipment is compact and practical. Suitable for filling 1-20KG open barrels (different filling capacity can be customized according to customer requirements). Place the empty bucket manually and activate the start button. After the filling is completed, the machine automatically lowers the cap and automatically presses the cover. After the cover is completed, it can be transported to the finished product conveyor to complete the entire operation process. The entire production process can be completed by only one worker. This type of filling machine greatly reduces the customer's production and labor costs, and is an ideal choice for enterprises.
Liquid quantitative filling machine is suitable for syrup, paint, paint, ink, adhesive, curing agent, resin, dye, cleaning Agents, motor oil, glycerin, lubricating oil, edible oil, flavors, solvents, additives, food additives, pesticides and other hazards Quantitative filling of sex chemical products.
Liquid quantitative filling machine is a device for automatic weighing and packaging of liquid materials in chemical, food, and other industries Prepare. Adopt high-precision all-electronic weight-weighing measurement to control the automatic quantitative filling and filling operations of the raw material barrels.
1.Touch-screen and instrument communication,directly on the touch screen adjustment measurement,without adjustment of the instrument's cumbersome procedures.
2.Automaic pressure cover, greatly save the time of manual pressure cover, improve efficiency and save labor
3.This type of filling machine is suitable 1-20KG(Other capacities can be customized) variety bucket,filling it with a flexiable, filling fast,accurate measurement,good stability,is not affected by the oil viscosity and temperature characteristics.
4.Suitable for the majority of small and medium enterprises small package filling, can filling paints,lubricants,fertilizer Syrup jam and other materials
Technical parameters:
| Model | FFC-1A |
| Filling capacity (KG) |
0.5-5 1-10 5-3010-50 (KG) (Other capacities can be customized) |
| Filling speed (BPM) | 2-6 B／Min |
| Power supply (VAC) | 380V 220V 50Hz |
| Power (KW) | 3.8 |
| Dimensions (MM) | 4200x1000x2200 |
| Net weight (KG) | 720 |
