| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE, ISO, SGS |
| Model Number: | FP-150C |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden packaged |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 100 pcs per month |
| Automatic Grade: | Automatic | Driven Type: | Pneumatic |
|---|---|---|---|
| Packaging Type: | Cartons, CANS, Bottles, Stand-up Pouch, Bags, Pouch | Packaging Material: | Plastic, Wood |
| Function: | Corner Trimming | Accuracy: | ±1% |
| Warranty: | 1 Year | Core Components: | PLC, Engine, Motor |
| Voltage: | 380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ | After-sales Service: | Video Technical Support, Free Spare Parts, Field Installation, Commmissioning And Training, Field Maintenance And Repair Service, Online Support |
| Highlight: | 2.8KW Spice Bottle Filling Machine,500G Bottle Powder Filling Machine,30BPM Bottle Powder Filling Machine |
||
Automatic Jar Can Coffee Milk Protein Spices Bottle Powder Filling Machine
This machine is an automatic powder and small particle filling machine, which can complete automatic bottle positioning, filling and metering. It consists of a filling head, a chain conveyor belt and a positioning device. It adopts a servo motor, PLC and Touch screen control, easy operation and high stability. It can be combined with bottle unscrambler, capping machine, labeling machine, etc. to form a complete filling line. It is suitable for packaging powder and small granular materials, such as powders, small granular medicines, veterinary drugs, glucose, condiments, solid beverages, carbon powder, talcum powder, pesticides, etc.
Features:
1 The exterior of the whole machine is made of stainless steel except for the motor; it can be easily removed and washed without tools.
2 The screw is driven by a servo motor, which has the advantages of not easy to wear, accurate positioning, settable speed, stable performance, etc.
3 Using PLC control, it has the advantages of stable work, anti-interference, and high weighing accuracy.
4 The Chinese and English touch screen clearly displays the working status, operation instructions, fault status and production statistics, etc., and the operation is simple and intuitive.
5 Various product adjustment parameter formulas can be stored for later use. Up to 10 formulas can be stored.
6 Replace the screw attachment, which can adapt to a variety of materials from ultra-fine powder to small particles.
7 Install a centrifugal device at the outlet of the flowing material to ensure accuracy, and install a dust suction device at the outlet of the dusty material to absorb the anti-spray dust.
Technical parameters:
| Model | FP-150C |
| Filling capacity (Gram) | 50-500 G (Can be customized according to customer requirements) |
| Filling speed (BPM) | 10-30 B／Min |
| Power supply (VAC) | 220/380V 50/60HZ |
| Power (KW) | 2.8 |
| Dimensions (MM) | 1800x980x1800 |
| Net weight (KG) | 460 |
