| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE, ISO, SGS |
| Model Number: | FZL-420 |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden packaged |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 100 pcs per month |
| Material: | 304 Stainless Steel | Automatic Grade: | Automatic |
|---|---|---|---|
| Key Selling Points: | High-accuracy, Easy To Operate | Application: | Food, MEDICAL, Chemical, Textiles |
| Driven Type: | Pneumatic | Packaging Type: | Bags, Film, Foil |
| Packaging Material: | Plastic | Function: | Vacuum, Sealing |
| Accuracy: | ±1% | Voltage: | 380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ |
| High Light: | 220VAC Industrial Vacuum Sealing Machine,0.6mpa Industrial Vacuum Sealing Machine,4times/Min industrial meat vacuum sealer |
||
1. Photoelectric tracking, color cover film or light film can be used for packaging, reduce costs and improve product quality.
2. This type of vacuum packaging machine adopts servo motor control system.
3. It can be equipped with an automatic coding system according to the user's product packaging requirements.
4. According to the user's product packaging requirements, on the basis of vacuuming, the vacuum packaging machine products can be filled with nitrogen or mixed gases for packaging.
5. Photoelectric eye automatic tracking equipment.
6. Using imported chains, it is suitable for stretching and forming of various thicknesses of soft film, hard film and semi-hard film, and can be specially packaged.
7. Equipped with corner waste recycling system to maintain environmental sanitation.
8. It adopts advanced pallet conveying structure, which is faster and easy to operate.
| Model | FVQ-420 |
| Power supply (VAC) | AC 380 220/50 60 |
| Vacuum pump displacement | 20×3 M³/H |
| Power | 10KW |
| Packing speed (BPM) | 4-10 Times／Min |
| Upper film width | 392 mm |
| lower film width | 422mm |
| Compressed air pressure | 0.6mpa |
| Dimensions (MM) | 6100×1200×1900 |
| Net weight (KG) | 720 |
