| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE, ISO, SGS |
| Model Number: | FCF-6A |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden packaged |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 100 pcs per month |
| Material: | 304 Or 316 Stainless Steel | Automatic Grade: | Automatic |
|---|---|---|---|
| Application: | Beverage, Food | Driven Type: | Pneumatic |
| Packaging Type: | CANS, Bottles, Stand-up Pouch, Film, Foil, Pouch | Function: | Sealing, Film Cutting |
| Warranty: | 1 Year | Core Components: | PLC, Engine, Motor |
| Voltage: | 380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ | After-sales Service: | Video Technical Support, Free Spare Parts, Field Installation, Commmissioning And Training, Field Maintenance And Repair Service, Online Support |
| Highlight: | 7.5KW Cup Filling Sealing Machine,5400B/H Cup Filling Sealing Machine,380V plastic cup sealing machine |
||
1.Highly Automate: Auto cup falling, filling, sealing, coding and output; And easy operate, high filling precision;
2.This Machine Is Suitable For The Packaging Of PP, PE,PET, Aluminum Foil And Other Materials, Suitable For The Sealing
3.The Whole Machine Can Be Produced with PLC, Pneumatic Control Component And Intelligent Digital Display Temperature Control System.
4.This kind of machine will be produced according to customer’s requirements; Picture just for reference.
5.This machine is specially designed for cups with rolled film or pre-cut lid products (or other kinds of liquid products, such as fruit juice, water and even granule and powder and others etc. ) to be filled and sealed.
6.This kind of machine can deal with some big cup need high capacity, the groove of the conveyer can be made up to a dozen and more .
| Model | FCF-6A |
| Power (KW) | 9 KW |
| Heat sealing power | 7.5 KW |
| Capping speed (BPH) | 5400 B/Hour |
| Power supply (VAC) | 380V 220V 50/60HZ |
| Dimensions (MM) | 4500x950x1700 |
| Net weight (KG) | 950 |
