| Place of Origin: | China |
|---|---|
| Brand Name: | Fair Machinery |
| Certification: | CE, ISO, SGS |
| Model Number: | FFD-A |
| Minimum Order Quantity: | 1 |
| Packaging Details: | wooden packaged |
| Delivery Time: | 10-20 days |
| Payment Terms: | T/T, Western Union. L/C |
| Supply Ability: | 100 pcs per month |
| Material: | 304 Or 316 Stainless Steel | Automatic Grade: | Automatic |
|---|---|---|---|
| Key Selling Points: | Fully Automatic, High-accuracy, Easy To Operate | Application: | Beverage, Food |
| Driven Type: | Pneumatic | Packaging Type: | CANS, Bottles, Stand-up Pouch, Film, Foil, Pouch |
| Packaging Material: | Paper, Plastic, Glass | Function: | Sealing, Film Cutting |
| Filling Accuracy: | ±1% | Warranty: | 1 Year |
| Core Components: | PLC, Engine, Motor | Voltage: | 380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ |
| After-sales Service: | Video Technical Support, Free Spare Parts, Field Installation, Commmissioning And Training, Field Maintenance And Repair Service, Online Support | ||
| Highlight: | 0.6MPa Soft Tube Filling Machine,2.2KW Lotion Tube Sealer,40B/Min Lotion Tube Sealer |
||
Features
1). With both tubes inner wall and external heating devices, ensures each tube tail sealed firmly, with high speed;
2). With mark locating sensor, can always seal the tubes at the same fixed position precisely;
3). Bucket with stirrer, can work with various liquid or cream, paste products;
4). Advanced PLC and touch screen operate system, easy to operate;
5). With graduator, ensures the rotary plate with the 8 (or 10) tubes can turn a precise same angle or circular distance each time;
| Model | FFD-A |
| Power (KW) | 2.2 KW |
| Speed (BPM) | 40-75 B/Min |
| Filling volume | 5-350ml |
| Filling accuracy | ≤±1% |
| Tube length | 50-240 |
| Tube diameter | Φ10- Φ50 |
| Tube material | Metal tube, ALU tube, Plastic tube, Compound tube |
| Working pressure | 0.5-0.6MPa |
| Power supply (VAC) | 380V 220V 50/60HZ |
| Dimensions (MM) | 2500x1200x2400 |
| Net weight (KG) | 1200 |
